Envistar Top with rotary heat exchanger and ThermoCooler HP
Envistar Top with rotary heat exchanger and ThermoCooler HP
We are launching a new website!

The reversible ThermoCooler HP heat pump can be integrated in our Envistar Top and Envistar Flex units.

![]() | ||
|---|---|---|
| Reversible heat pump | ||
28 | ||
22 | ||
17 | ||
12 | ||
10 | ||
09 | ||
06 | ||
m³/s 0.00.51.01.52.02.53.0 | ||
![]() | ||
|---|---|---|
| Reversible heat pump | ||
1280 | ||
1080 | ||
980 | ||
850 | ||
740 | ||
600 | ||
480 | ||
400 | ||
360 | ||
300 | ||
240 | ||
190 | ||
150 | ||
100 | ||
m³/s 0.02.04.06.08.010.012.0 | ||

Envistar Top with rotary heat exchanger and ThermoCooler HP

Envistar Flex with rotary heat exchanger and ThermoCooler HP
Here you will find dimensions and weights as well as power and performance information about ThermoCooler HP.
| Size | Cooling recovery | Dimension (mm) | Weight (kg) | System voltage | ||
|---|---|---|---|---|---|---|
| Width | Height | Length | ||||
100-2V | - | 1360 | 1090 | 790 | 220 | 400VAC |
100-4V | Yes | 1360 | 1090 | - | - | 400VAC |
150-2V | - | 1460 | 1470 | 790 | 260 | 400VAC |
150-4V | Yes | 1460 | 1470 | - | - | 400VAC |
190-2V | - | 1740 | 1470 | 790 | 290 | 400VAC |
190-4V | Yes | 1740 | 1470 | - | - | 400VAC |
240-2V | - | 1740 | 1686 | 790 | 310 | 400VAC |
240-4V | Yes | 1740 | 1686 | - | - | 400VAC |
300-2V | - | 1956 | 1686 | 790 | 370 | 400VAC |
300-4V | Yes | 1956 | 1686 | - | - | 400VAC |
360-1V | - | 1956 | 2060 | 890 | 425 | 400VAC |
360-2V | - | 1956 | 2060 | 890 | 425 | 400VAC |
400-1V | - | 1740 | 2060 | 890 | 400 | 400VAC |
400-2V | - | 1740 | 2060 | 890 | 400 | 400VAC |
400-4V | Yes | 1740 | 2060 | - | - | 400VAC |
480-2V | - | 2330 | 2060 | 890 | 510 | 400VAC |
480-4V | Yes | 2330 | 2060 | - | - | 400VAC |
600-2V | - | 2540 | 2270 | 890 | 630 | 400VAC |
740-2V | - | 2820 | 2675 | 890 | 740 | 400VAC |
850-2V | - | 2900 | 2935 | 890 | 790 | 400VAC |
980-2V | - | 3200 | 3085 | 890 | 900 | 400VAC |
1080-2V | - | 3340 | 3195 | 890 | 1260 | 400VAC |
1280-2V | - | 3520 | 3375 | 890 | 1380 | 400VAC |
Here you will find general documentation for this product series. Download the latest versions of product brochures, instruction manuals, certificates, and other documents.
If you are looking for information about your AHU, search using the order number.
Document | Document type | Language | Version | Download/Share | |
|---|---|---|---|---|---|
| Loading… | |||||
Together, let's find the optimal solution for you!
Document | Document type | Language | Version | Download/Share | |
|---|---|---|---|---|---|
Brochure | English | 1 | |||
Operation and maintenance | English | 04 | |||
Assembly instruction | English | 06 | |||
Assembly instruction | English | 04 | |||
Configuration and settings | English | - | - | ||
Configuration and settings | English | - | - | ||
Certificates and declarations | Swedish/English/German/Norwegian/Danish | - | 2025 |
